This addressable CCT tunable COB LED strip lets you shift the white light any where from warm 2700K to cool 6000K, with each section individually controllable pixel by pixel over SPI or DMX. Unlike a standard analog CCT strip that adjusts the whole run as one, this digital version gives you pixel-level control over colour temperature across a single spotless 10mm tape - so you can create warm-to-cool gradients and dynamic white scenes from one 24V strip with a dot-free COB face.
|
Parameter |
Value |
|
SKU |
COBD-560-CCT-505 |
|
Chip type |
COB (Spotless) |
|
Light type |
CCT Tunable (white) |
|
Colour temperature |
2700K - 6000K |
|
LEDs per metre |
560 |
|
Voltage |
24V DC |
|
Power per metre |
9W |
|
Luminous flux |
660 lm/m |
|
CRI |
Ra90 |
|
Ingress protection |
IP20 (non-waterproof) |
|
Strip width |
10mm |
|
Copper trace thickness |
2oz |
|
PCB layers |
Double layer (PRO Version) |
|
Control protocol |
Addressable Digital SPI / DMX |
|
Roll length |
30m (full roll) |
Choose this addressable CCT tunable version if you want pixel-level control over white colour temperature - warm-to-cool gradients, zoned scenes and dynamic white effects across the run. If you only need to set one colour temperature at a time for the whole strip, a standard (non-addressable) CCT tunable strip will be simpler and cheaper to control. At 10mm wide and 9 W/m, this is a slim, moderate-output white strip; if you need a wider tape or higher brightness, check the higher-power versions in the range. This is an IP20 strip for dry indoor use only; for moisture-prone areas (bathroom, kitchen splash zones, outdoors), choose a waterproof IP-rated version.
This strip runs on a dedicated 24V DC power supply and cannot be connected directly to mains - size the driver with roughly 20% spare headroom. Because it is addressable, it also needs a compatible SPI / DMX controller or decoder to drive the pixel data; a plain analog CCT controller will not work. Cut only at the marked cut points along the strip, and mount it in a suitable aluminium profile for the best heat dissipation and finish.
Each section of the strip can be controlled individually (pixel by pixel) via an SPI or DMX signal, so you can vary colour temperature along the run, not just set one white across the whole strip.
A standard CCT strip changes colour temperature as one block. This digital version adds an IC-driven data line so the strip is individually addressable, while still tuning across the same 2700K to 6000K white range.
Anywhere from 2700K (warm white) to 6000K (cool daylight white), plus every step in between.
No — it's rated IP20 with no protection against moisture. For wet or outdoor areas, choose a waterproof (IP-rated) version instead.
Yes. It requires an SPI / DMX-compatible controller or decoder to run the addressable effects, plus a standard 24V DC driver for power.
| Color Changing | CCT Tunable |
|---|---|
| Watts per meter | 9 |
| Water Resistance | IP20 Non Waterproof |
| Voltage | 24V |
| Lumens per meter | 660 |
| Number of LEDs/ Meter | 528 |
